Endress+Hauser CPS11D-7BA2C1
Endress+Hauser CPS11D-7BA2C1
Measuring principle:Potentiometric
Application
Long-term monitoring, processes with little change
Water and wastewater treatment
Characteristic
Analog, digital pH electrodes for standard applications in process and environmental technology
Dirt-repellent PTFE diaphragm, built-in temperature sensor
Measuring range
pH 0 to 14
Measuring principle
Gel compact electrode with PTFE ring-diaphragm
Design
All shaft lengths with temperature sensor
Advanced gel technology
Digital electrode with Memosens technology
Material
Glass and PTFE
Dimension
Diameter: 12 mm (0. 47 inch)
Shaft length: 120, 225 and 360 mm
(4. 72, 8. 86 and 14. 17 inch)
Process temperature
0 to 135 °C (32 to 275 °F)
Process pressure
1 to 17 bar (15 to 246 psi)
Temperature sensor
NTC 30k
Ex certification
ATEX, FM, CSA, NEPSI
Connection
Inductive, digital connection head with Memosens technology
Ingress protection
IP68
Additional certifications
Also available as SIL version
Your benefits
• Low-maintenance and robust thanks to large, dirt-repellent PTFE ring junction
• Can be used at pressures up to 17 bar (246. 5 psi) (absolute)
• Process glass also for very alkaline applications (BA and BT versions)
• Process glass for applications in media containing hydrofluoric acid (FA version)
• For media with low conductivity (AS version)
• Integrated NTC 30K (Memosens) temperature sensor for effective temperature
compensation
• Optional: poison-resistant reference with ion trap
Other advantages provided by Memosens technology
• Maximum process safety
• Data security thanks to digital data transmission
• Very easy to use as sensor data are saved in the sensor
• Predictive maintenance can be performed with the Memobase Plus CYZ71D by
recording sensor load data in the sensor
