Endress+Hauser Vibronic Point level detection Soliphant FTM50-AG
Endress+Hauser Vibronic Point level detection Soliphant FTM50-AGG2A2A12AA
Specs at a glance
Process temperature
-50°C . . . 280°C
(-60°F . . . 540°F)
Process pressure / max. overpressure limit
Vacuum . . . 25 bar
(Vacuum . . . 360 psi)
Min. density of medium
Standard fork: 10 g/l
Short fork: 50 g/l
Field of application
Soliphant FTM50 is a robust point level switch for use in silos containing fine-grained or powdery solids even with a low bulk density. Suitable for a wide range of applications with international certificates for use in dust or gas hazardous areas. Available with polished fork and stainless steel housing with Tri-Clamp or with aluminum housing and coated fork. Maintenance-free device for use in typical applications like: cereals, flour, cocoa, sugar, animal feed, dye powder, chalk.
Point level switch for fine grained solids and powder.
Process connections: Threads, flanges and hygienic connection (Tri-Clamp)
Temperature: -50 to +280°C (-60 to +540°F)
Pressure: -1 to +25bar (-14. 5 to +360psi)
Sensor length: 145mm, 200mm
Sensor material: 316L (3, 2µm, 0, 8µm, PTFE coated, ETFE coated)
International explosion protection certificates
Benefits
SIL2 in accordance with IEC 61508
No mechanically moved parts, free of maintenance
Measurement not affected by build-up or external vibration
Various electronic inserts: e. g. NAMUR, relay, thyristor and PFM-signal outputs for optimum alignment with the plant control system
Build-up and abrasion display selectable, density setting and switching delay selectable
Choice of coated or polished sensor
Build-up and corrosion detection
Measuring principle
Vibration Solids
Characteristic / Application
Compact point level switch for fine grained solids and powder
Grain size <= 10 mm (<= 0. 39 in)
Fork sensor
No calibration required
Not affected by build-up or external vibration
Robust
Switch value visible from outside
Specialities
Build-up and corrosion detection
Remote version
3 temperature versions available
SIL 2
Supply / Communication
10-55V DC PNP 3-wire
19-253V AC 2-wire
19. . . 253V AC / 19V. . . 55V DC 2 relay contact
8/16mA
NAMUR
PFM
Ambient temperature
-50°C . . . 70°C
(-60°F . . . 160 °F)
Process temperature
-50°C . . . 280°C
(-60°F . . . 540°F)
Process pressure / max. overpressure limit
Vacuum . . . 25 bar
(Vacuum . . . 360 psi)
Min. density of medium
Standard fork: 10 g/l
Short fork: 50 g/l
Main wetted parts
selectable:
316L 3, 2um
316L 0, 8um
316L PTFE coated (to avoid build-up)
316L ETFE coated (to avoid corrosion)
Process connection
Thread
R 1 1/2"
1 1/4" NPT
1 1/2" NPT
EN Flange DN50. . . DN100
ASME Flange 2". . . 4"
JIS Flange 50A. . . 100A
Process connection hygienic
Tri-Clamp ISO2852
Sensor length
Standard: 200mm (8")
Short: 145mm (5. 7")
Communication
DC PNP 2-wire
AC Thyristor
DPDT relay
8/16mA
NAMUR
PFM
Certificates / Approvals
A
